Bigblue Camera Tray Kit with Two Lights and Protective Case

This kit is a complete two-light camera rig in a hard case. You get an AL1300WP and an AL1300XWP light, a dual-arm camera tray, two CLIP-02 double clips and two DA-009 adapters, all packed in Bigblue’s PC105A protective case. Add your camera and you’re ready to dive.

The two lights share a body and a power system but differ in beam. The AL1300WP spreads 1300 lumens of 6500K light into an 85° wide beam through a convex lens. The AL1300XWP spreads the same output into a 120° beam behind tempered optical glass. Each light steps down from 1300 to 650, 325 and 130 lumens, for 2, 5, 10 and 20 hours, and has an SOS mode.

Each runs on its own rechargeable 18650 battery with a USB charger. Bigblue suggests 3–4 hours for a full charge. A body-mounted push button with a battery indicator runs every mode. Both lights are tested to 100 m and come with yellow and red filters.

Each light’s mounting clip takes a DA-009 adapter, which gives it a 1-inch ball. The CLIP-02 double clips join those balls to the tray arms. The tray has a GoPro-style mount and a 1/4-20 mount for GoPro, DJI Osmo Action, Insta360 Ace Pro and similar cameras.

The PC105A case measures 420 x 360 x 130 mm outside, so the rig, chargers and filters travel together.

Specifications
Kit
- Max output: 2 x 1300 lm
- Beam angle: 85° & 120°
- Burn time: 2–20 hrs
- Modes: 4 levels + SOS
- Lights in the kit: AL1300WP (85° wide) + AL1300XWP (120° wide)
- Case: PC105A hard protective case
- Case exterior: 420 x 360 x 130 mm (16.5 x 14.2 x 5.1 in)
- Case interior: 380 x 310 x 120 mm (15.0 x 12.2 x 4.7 in)
- Camera: Not included
Both lights
- Light source: 1 x XML LED
- Power levels: 1300 · 650 · 325 · 130 lm, plus SOS
- Color temperature: 6500K
- Burn time by level: 2 · 5 · 10 · 20 hrs (level IV to I)
- Battery: 18650 Li-ion rechargeable
- Charger: USB charger
- Charge time: 3–4 hrs (Bigblue suggested)
- Switch: Body-mounted push button with battery indicator
- Filters: Yellow (FILYEL35) and red (FILRED35)
- Casing: Anodized aluminum alloy
- Max depth: 100 m tested (328 ft)
- Buoyancy in seawater: -84 g (-3.0 oz) with battery
- Light head: Bigblue modular Type I
AL1300WP
- Beam angle: 85° wide
- Front glass: Convex lens
- Size: Dia. 35.5 x L 126.3 mm (1.4 x 5.0 in)
- Weight in air: 162 g (5.7 oz) with battery
AL1300XWP
- Beam angle: 120° wide
- Front glass: Tempered optical glass
- Size: Dia. 35.5 x L 122.1 mm (1.4 x 4.8 in)
- Weight in air: 160 g (5.6 oz) with battery
Tray and clips
- Tray: Dual-arm camera tray (BBGPTRAY)
- Camera mounts: GoPro-style prong mount and a 1/4-20 mount
- Fits: GoPro, DJI Osmo Action, Insta360 Ace Pro and more
- Double clips: 2 x CLIP-02, 64 mm (2.5 in) long, T6061 aluminum
- Adapters: 2 x DA-009 Sea & Sea standard, 1-inch ball, 2.5 in long
