The innovative Maxifilter system guarantees the highest air purity, adhering to DIN EN 12021 standards. Moisture is effectively eliminated thanks to the strategic placement of the filter system after the separator stages, making it ideal for both professional and recreational use.

Designed for convenience, the chassis allows for easy portability, featuring handles and a compact frame. Whether you require a single-phase or three-phase electric motor, options ranging from 3 to 5.5 kW ensure you have the power you need. Choose Coltri for a reliable air solution that prioritizes safety and performance. Order yours today and experience the difference.

TECHNICAL DATA:

• Dimensions: 100 x 46 x 70 cm, 39.4 x 18.1 x 27.6 in
• Type of gas Breathing air (EN 12021) – Nitrox 40% max O2 – Helium – Nitrogen
• Intake pressure Atmospheric max 300 millibars
• Permissible ambient temperature range -10 C Ã +40 C
• Permissible altitude 0 Ã 1.500 m SLM
• Max permissible tilt 6
• Design Basic
• Operating voltage, standard 230 V; 50 Hz / 400 V; 50 Hz
• Other operating voltage On three-phase electric motor at 60Hz the power (kW / Hp) increases by 20%. 230 V, 50 Hz / 440 V, 60 Hz
• Oil Synthetic Coltri Oil ST 755
• Oil change interval 1 year / 1,000 h
• Frame Steel thickness 1.5 mm – color RAL 5015 – Powder coating – scratch-resistant
• Purification System: Maxifilter
